TotalPurge is the AutoCAD app for complex drawing optimization

  Overview:
  Optimization:

Efficiently clear drawings and convert objects to polylines
with TotalPurge the drawing optimization solution for AutoCAD

Download TotalPurge
Buy now TotalPurge
Watch video about TotalPurge
  TotalPurge is a powerful compact tool to be run in AutoCAD environment, created specially to bring order to DWG drawings, which allows you to quickly clear drawings of excessive graphic constructions, as well as to convert various types of objects to polylines.

Key drawing optimization features:
  • Finding and removing duplicate objects.
  • Finding and removing objects located in overlapping areas of other objects.
  • Finding and replacing two or more co-directional objects forming an interface node with a single entity.
  • Finding and replacing two or more co-directional objects partially overlapping each other with a single entity.
  • Replacing serial collinear chains of same objects with a single object.
  • Finding and removing redundant vertices in polylines (POLYLINE, LWPOLYLINE).
  • Optimizing jointly and separately entities LINE, CICRLE, ARC and polylines POLYLINE, LWPOLYLINE.
  • Properly handling entities located in different planes and ensuring 100% support for all user coordinate systems (UCS).
  • Two built-in optimization methods.
  • High performance compared to existing competitors (OVERKILL).
  • More on optimization...

Additional optimization features:
  • Finding and removing lines of short length.
  • Finding and removing circles and arcs of small radius.
  • Bridging gaps in various entity combination interface nodes (including those forming closed areas).

Converting entities of various types into polylines:
  • Converting joint entities into multiple-vertice polylines (smart conversion).
  • Converting entities forming closed loop into closed polylines.
  • Option to convert entities into polylines on the “as is” principle (trivial conversion).
  • Converting spline objects (SPLINE, ELLIPSE, POLYLINE) into optimized polylines LWPOLYLINE.
  • Option to convert spline objects into polylines using approximation by both line and arc segments.
  • More on conversion...

Block operations:
  • Converting geometrically identical closed two-dimensional contours into a set of same-type blocks using the new efficient block creator .
  • Optimizing data within blocks using all the above mentioned features.
  • Converting objects into polylines within blocks using trivial and smart conversion methods.
  • High performance when processing great numbers of blocks.

Other features:
  • Running in a dedicated thread.
  • Synchronizing and bringing entity normal vectors to uniformity.
  • Increased protection in data processing. All object manipulation procedures are carried out in hidden records.
  • Improved rollback (undo) function, preventing corruption of data in case of abnormal termination of the application.

Benefits of using the software:
  • Significant decrease of drawing file size (especially for large drawings consisting of numerous primary units) up to 15% and more.
  • Accelerated performance when working with drawings (due to reduced drawing size) after optimization (especially when working with large drawings).

Convenient friendly interface:
  • Simplicity and ease of installation using the classic installer.
  • Toolbar for quick and easy launching.
  • Selection of both individual drawing fragments and all objects on current layout.
  • Sophisticated application settings window.
  • Assigning new properties to objects prior to launching optimization.
  • Comprehensive help system.
  • Automatic serial optimization of entities on all layers.
  • Improved user interface.

Support for major versions of AutoCAD:
  • AutoCAD 2013 (x86)(x64)
  • AutoCAD 2014 (x86)(x64)
  • AutoCAD 2015 (x86)(x64)
  • AutoCAD 2016 (x86)(x64)
  • AutoCAD 2017 (x86)(x64)
  • AutoCAD 2018 (x86)(x64)
  • AutoCAD 2019 (x86)(x64)
  • AutoCAD 2020 (x64)
  • AutoCAD 2021 (x64)
  • AutoCAD 2022 (x64)
  • AutoCAD 2023 (x64)
These features make TotalPurge a perfect solution for cleaning and optimizing DWG drawings (especially when dealing with a large volumes of electronic documentation), as well as drawings obtained by exporting from engineering and graphic design suites, such as Autodesk Inventor, SolidWorks, SolidEdge, CorelDraw, etc.
For more information on the application, please check out its description.
